Slimbox ® is a renowned and established brand in Australian signage and display industries. We specialise in design, manufacture and distribute compact, versatile, aesthetic LED back lighting solutions to increase energy efficiency and reduce the carbon footprint for the signage, architectural, commercial and industrial market. Slimbox® product categories range from slim lightbox, magnetic front open lightbox, snap frame lightox, soft fabric lightbox, acrylic lightbox, menu lightbox, under awning lightbox, outdoor lightbox, directory lightbox, freestanding lightbox, LumiPANEL® and Digital Printing. We built entirely base on Australian Standards with 12 month warranty. We also stock standard sizes for same day delivery service to Sydney metro area and overnight service for most cities around the country.

DL Lite

DL Lite Front Open is the premium solution for small-medium sized display applications. Its thin and light chassis provides the ultimate versatility for Recess, Mount, Hang setups.

Every DL Lite is built strictly based on Australian Standard and assembled in our Sydney production facility. We stock standard sizes and custom built to client's specifications.

The lightbox's chassis is made from the compact yet durable DL18 aluminium extrusion, 18mm Deep, comes in Anodised Silver/ Satin Black Frame, with a standard 30mm Silver/Black matching border. The 30 years non-yellowing clear acrylic face is fitted with easy-to-access Magnetic Secure System. DL Lite's standard sizes all come with Magnetic Image Holder as standard.

The lightbox is configured with Engraved Lumipanel® with PVC backing, edgelit setup using 12v efficient and bright LED strips.

This product is designed for indoor use only with 12 month warranty.



Front Open Series - DL Lite




Overview

DL Lite Front Open is the premium solution for small sized display applications. Its thin and light chassis provides the ultimate versatility for recess, mount and hang setups.

DL Lite's chassis is made from the compact yet durable DL18 aluminium extrusion, 18mm deep, comes in an anodised silver/satin black frame, with a standard 30mm silver/black matching border. The 30 year non-yellowing edge-to-edge clear acrylic face is fitted with an easy-to-access magnetic secure system. DL Lite's standard sizes come with a magnetic image holder as standard.

Recommended Sizes

200x200mm to 1000x1800mm

LED Specs

DL Lite is configured with the industry leading lumiPANEL®. Edgelit setup using latest 12/24v efficient and durable(approx 40,000 hrs normal usage) high lumen density SMD LEDs, achieve up to 5000lux. Choose from 3000-10000 kelvin colour temperature. AC/DC adaptor/power supply included.

Warranty

Every DL Lite is built strictly based on Australian Standard and assembled in our Sydney production facility. We stock standard sizes and custom built to client's specifications. This product is designed for indoor use only with 12 month warranty.




Product Specifications


Bezel Width 25mm (Vary) DLL
Depth Height 18mm
Light Source LED
Availability Face Holder Face/Backing Light/Parts Installation
Custom Built A Snap-lock N/A 1mm clear PETG face N/A Edgelit S Outdoor use A
Standard Sizes A Magnetic S 2mm clear acrylic face O Backlit N/A Wall Mount S
Colour Lockable N/A 3mm clear acrylic face S Built-in adaptor N/A Freestanding O
Black  S Insert N/A 3mm opal acrylic face O External adaptor S Suspension O
Silver S Image Holder 3mm clear polycarbonate O 1m Cable S 3D Lettering O
Custom colour O Magnetic O 3mm PVC backing S Extended cable O
    Double side tape S 3mm ACP backing O
    Clip/Sandwich N/A S: Standard   O: Optional   A: Available   N/A: Not available


Standard Sizes

DLLA3 335x460mm available in Silver or Black

DLLA2 460x635mm available in Silver or Black

DLLA1 635x880mm available in Silver or Black

DLLA0 880x1225mm available in Silver or Black

DLL612 600x1200mm available in Silver or Black


Custom Built


Available on Slimbox® Store

FRONT OPEN - DL Lite 1000x600mm
from 250.00

DLL 1000x600mm Silver

Designed and Assembled in Sydney, 12 Month Warranty;

Available to Ship: Limited stock, Australia Wide;

Prices are exclusive of GST & delivery charges.

Choose a Print:
Quantity:
Add To Cart

FRONT OPEN - DL Lite (Std. Sizes)
from 130.00

DLL A4 - 250x338mm

DLL A3 - 335x460mm

DLL A2 - 460x635mm

DLL A1 - 635x880mm

DLL A0 - 880x1225mm

DLL 612 - 600x1200mm

Designed and Assembled in Sydney, 12 Month Warranty;

Available to Ship: In-stock, Australia Wide;

Prices are exclusive of GST & delivery charges.

Choose a Size:
Choose a Colour:
Choose a Print:
Quantity:
Add to Cart
